Output Voltage 5 V ± 2%
Ouput Current up to 150 mA
Very Low Current Consumption
Power-on and Undervoltage Reset with Programmable Delay Time
Reset Low Down to V Q = 1 V
Adjustable Reset Threshold
Very Low Dropout Voltage
Output Current Limitation
Reverse Polarity Protection
Overtemperature Protection
Suitable for Use in Automotive Electronics
Wide Temperature Range -40 °C ≤ T j ≤ 150 °C
Input Voltage Range from -42 V to 45 V
Integrated Pull-Up Resistors at Logic Outputs
Green Product (RoHS compliant)
AEC Qualified
